Project Highlights

Agile Tropicana

Future Growth of
Our Nation over

MRT Tunnels

AGILE Tropicana has engaged G&P Professionals Sdn Bhd to assess the impact of the proposed high rise mixed development to the future MRT tunnels as the future KVMRT Line 2 tunnels (Northbound and Southbound) will have its proposed alignment cutting across the project site.

Project Challenges

One of the biggest challenges of this project is to control the movement of the MRT tunnels within the stringent criteria according to Railways (Railway Protection Zone) Regulations 1998 (PU(A) 367 1998). Some of the important criteria are listed as follows:

  • Total movement < 15mm in any plane.
  • Differential movement < 3mm in 6m (1:2000) in any plane.
  • No sheet piles, piles, foundation, boreholes or wells shall be driven within First Reserve.
  • For the pile foundation constructed in the Second Reserve, the piles are designed so that they are debonded within the zone of influence of the underground structure and develop all of their load either in shear or end bearing from soil located below zone of influence of the structure.
  • To assess the anticipated movement of the MRT tunnels due to the development
  • To model complex soil-structure interaction (i.e. MRT tunnels at varying depths and orientations)
  • To examine the proposed piled foundation with non-regular loadings pattern that could not be properly modelled and assessed using 2D analysis
Double Track

Double Track

THE CHALLENGES

The railway tracks transverse a distance of 350km from north to south passing through subsoils which vary from soft alluvium deposits to dense residual soils. In addition, the geometrical tolerance of the railway tracks is very stringent, especially for trains with high design speeds of 180km/hr. The design performance requirements include differential settlement of not more than 10mm over a chord length of 10m and settlement of not more than 25mm within 6 months after completion.
Hence, various ground treatment techniques were adopted to meet the performance requirements and construction schedules, especially when long stretches of the embankment supporting the tracks traverses very soft to soft alluvium deposits with thickness of 15m to 20m.

ADOPTED GROUND TREATMENT TECHNIQUES:

  • Excavation & Replacement of soft soil
  • Surcharging
  • Prefabricated Vertical Drain
  • Stone Column

DESIGN OF EMBANKMENTS:

  • Settlement Analyses
  • Stability Analyses
  • Dynamic Analyses
  • Embankment Behaviour on Soft Ground
Top: Temporary Sheet Pile for Excavation and Replace Method (E&R).
Top: Typical PVD Machine working beside the Live Track

Right: Embankment fill with surcharge next to existing live tracks

Draw Bridge

Pioneering Malaysia’s First

Drawbridge

DRAWBRIDGE that links Muara North and Muara South (two reclaimed areas on the north and south of Terengganu River) to create a strategic connection between Kuala Terengganu City across the north and south of Terengganu River, which leads all the way to Kuala Terengganu’s Sultan Mahmud Airport. G&P Geotechnics Sdn Bhd have been engaged by Zelan-Hasrat Sedaya Consortium to provide alternative design for pile cap and foundation system of four (4) marine piers (namely Pier P3, Pier P4, Pier P5 and Pier P6).

The subsoil condition is summarised in Figure 1.

“The challenge is to ensure the foundation movements are within drawbridge operation limits with lateral loadings such as wind loads or vessel collision.”

Ir. Koo Kuan Seng (Project Engineer)

Figure 2: Site Condition during Construction of Pile Cap

Design Requirement

  • Vertical settlement of pile group < 10mm.
  • Lateral displacement of pile group limited to 20mm in any direction.
  • Pile cap crack width requirement = 0.1mm (Table 1 in BS5400-4 “Extreme Environment” for marine structures with concrete surface exposed to abrasive action by sea water).
  • Accidental ship impact load.
  • Wind load on drawbridge and towers.
Figure 3: Overall Piling Condition

Design Methodology

Pile Group Analysis

Pile group analysis was carried out using PIGLET software (soil-structure interaction software for pile group analysis developed by M.F.Randolph).

Design loads were provided by bridge engineer with all the load cases in service limit state (SLS) and ultimate limit state (ULS).

Design Pile working capacity for 1m diameter precast spun pile is 5500kN.

Design Lateral working load for 1m diameter precast spun pile is 135kN.

Pile Cap Analysis

Pile cap Structural analysis was carried out using SAFE version 12

Figure 6: Site Preparation for Lateral Pile Load Test

Figure 7: During Preparation for Pile Cap Casting

Figure 8: Piling Layout Plan

Figure 4: During Preparation of Statnamic Test

Figure 5: During Installation of Raked Pile

Preliminary Pile Test

Maintained Load Test

The average settlement for 100% working load is 8.98mm which satisfies the design criteria.

Lateral Pile Load Test

Non-linear yielding behavior of the pile deflection is observed during lateral pile load test on site.

Back analysis based on lateral pile load test concluded that the actual subsoil shear modulus is lower than the value adopted in the design assumption. Thus, pile group re-analysis was carried out based on the updated subsoil shear modulus.

Summary of Alternative Design

Original design of 15 nos. of 1000mm diameter bored pile for Pier P3 was replaced with alternative design of 28 nos. 1000mm precast spun pile (combination of vertical and raked piles)

Original design of 55 nos. of 1500mm diameter bored pile for Pier P4 and P5 were replaced with alternative design of:

  • 118 Nos. 1m dia. precast spun pile (combination of vertical and raked piles)
  • 86 Nos. vertical pile.
  • 32 Nos. raked pile
  • Pile length = 30m – 36m
  • Pile cap area = 1932m2
  • Pile cap volume = 7025m3

Initial design of 15 nos. of 1000mm diameter bored pile for Pier P6 was replaced with alternative design of 24 nos. 1000mm precast spun pile (combination of vertical and raked piles).

Figure 9: Aerial View

XMU

First Overseas Campus

approved by Chinese Government

Consisting of 5 multi-storey academic blocks on a car park podium, a science centre with an arts auditorium, a student activity centre with multi-storey sports facility, 5 multi-storey student accommodation buildings, a multi-storey restaurant, a clock tower and an amphitheatre.

Slanted Columns & Ring Beams

The A3 block is the main academic block and the largest structure in the university campus with a total floor area of 58 598 m2. This block houses a 7-storeys library with the centre of each floor being a large atrium space with an increasing diameter at each floor, featuring the structural slanted columns that have been placed at its perimeter. The slanted columns and the ring beams were further analysed to confirm the behaviour of the unique structural elements. The ring beam with the floor slab behave like a tie beam and restraints the movement of the slanted columns in the horizontal direction.

Sloping Roof

The A1, A2, A4, and A5 academic blocks are the other academic blocks with a total floor area of 21 854 m2 over 5 floors. Within these blocks, all the teaching and learning facilities such as lecture halls and teaching rooms are provided. At the centre of each floor is a large atrium at each floor where large circular voids were created. The roof structure for A1, A2, A4 and A5 blocks was designed and constructed as reinforced concrete structure due to architectural requirements on the laying of the roof tiles. Hence, the casting of the sloped roofs were done in several layers to achieve the required finish quality and consistency.

  1. Casting sequence of concrete roof beam and slab in a few of horizontal layers
  2. Schematic diagram indicating loadpath for ring beam (tension) and slanting column (compression)
  3. Constructed slanting columns and ring beams
  4. Aerial view of A4 block in construction

Yearly Project List

2018

Projects Name Scope
Smart Tunnel Maintenance Depot Office at Tun Razak Exchange Independent Geotechnical Review of Micropile Foundations
South Klang Valley Expressway (SKVE) Due Diligence
Sabah Sarawak Gas Pipeline – Gas Leak Expert Opinion
Geotechnical Consultancy at Lot PT1052 (HSD115367) Seksyen 54 Jalan San Peng Geotechnical Consultancy Services
Proposed Bridge at One Foresta Development, Bayan Lepas, Penang Full Geotechnical & Bridge Consltancy Services
Tapah Plant, Perak Geotechnical & Hydrogeological Investigation for:

a) The impact of quarry on the east side of plant

b) The long-term impact on deep & shallow foundation of the plant with quarry extension on the north side of plant

c) Impact on stability of overburden dumpling area next to the plant

2017

Projects Name Scope
Investigation of Collapsed Reinforced Concrete (RC) Wall and Review of Existing RC Wall for Kajang East, Semenyih, Selangor Failure Investigation and Independent Design Review of Existing RC Wall
Proposed Development at Jalan Peel Land Geotechnical Consultancy Service
Elmina East Innovation Gallery Geotechnical Consultancy Services for Local C&S
Bangi Estate, Bangi Semenyih Geotechnical Consultancy Services for Main Earthworks
Cadangan Pembangunan Di Atas Lot 48731 (PT45264) Mukim Petaling, Daerah Petaling, Selangor Darul Ehsan Geotechnical Consltancy Services for Basement and Foundation Works
Proposed Apartment Development at Bukit Tunku, Kuala Lumpur Geotechnical Consultancy Services
East Coast Rail Link – Bentong to Gambang, Pahang Concept Geotechnical Design
Potential Development in Puchong Jaya on Lot PT25068, Selangor (170 Acres) (Puchong Land) Subsurface Investigation (S.I) for Feasibility Study
Panel Checker for Proposed Development in Putrajaya and other Project Sites Panel Checker Geotechnical Engineering Consultancy Services
Proposed Reclamation and Development of About 1005 Acres (407 Hectares) of Coastline Along Butterworth, Penang Geotechnical & Maritime Engineering Consultancy Services for Preparation of Reclamation Masterplan
Gamuda Garden, Bandar Serai Development Sdn Bhd Full Geotechnical Consultancy Services on Foundations
Proposed Mixed Development on Lot 8596, 9514 & 9515 at Tanjung Karang, Kuala Selangor Geotechnical Engineering Consultancy Services
Wellington Phase 3, Wangsa Maju, Kuala Lumpur Foundations Design Consultancy Services
Proposed Redevelopment at Lot 63, Jalan Gurney, Kuala Lumpur Foundation/Basement
Independent Power Plant F  oundation/Basement
Project Q plot 1, Taman Equine Full Geotechnical Consultancy Service on Foundation Design
Condominium Development on Lot 1478, Taman Bukit Desa, Mukim Kuala Lumpur Full Geotechnical Consultancy Services
Review on Existing Cast In-Situ Reinforced Concrete (RC) Wall For Kajang East, Semenyih, Selangor Darul Ehsan Geotechnical Review for Cast In-Situ Reinforced Concrete Wall
Hanson Segamat Quarry Consultancy service on Investigation into the Quality and Consistency of Basalt Aggregates, and check on the Available Reserve of the Gravels
Langkawi Coastal Reservoir Consultancy Services
HSR (KL to Singapore) – RDC02 Foundation/Basement
Hanson Segamat Quarry Foundation/Basement
East Coast Rail Link (ECRL) – SI Technical Proposal for Lead Consultancy Service for Soil Investigation
Lot PT24, Jalan Pekeliling, Seksyen 47, Kuala Lumpur Independent Geotechnical Review on proposed Foundation Design
Cadangan Jalan Sambungan Dari Persiaran Cassia Barat 3 Ke Lift Pump Station Di Atas Lot 282, Batu Kawan, Pulau Pinang Tingkat FASA 1A, Jalan Segambut, Kuala Lumpur Geotechnical Engineering Consultancy for Ground Treatment Design
FEED Services for Kerteh 2 Project Front End Engineering and Design of KERTEH 2 Project Foundation/Basement
Proposed Development on Lot 2356, Mont’ Kiara, Mukim Batu, Kuala Lumpur Hill Site Development
Kek Lok Si, Penang – Phase 2 Hill Site Development
Independent Checker for KL East (FASA 2) Hill Site Development
Mixed Development on Lot 158, 159, PT12 & 163, Jalan Syed Putra,KL Geotechnical Consultancy Service
Sunway Jalan Belfield, Kuala Lumpur Geotechnical Consultancy Service
Review of HDD at KM4.8 Bkt Kayu Hitam, NSE Geotechnical Engineering Review Consultancy Services
Police Headquarters at Bagan Datuk, Perak Geotechnical Consultancy Service on Ground Treatment and Foundation
Monash University Southern Extension Geotechnical Consultancy Service
Feasibility Study of Development of Taman Equine and Sungai Besi Hill

2012 - 2016

Projects Name Scope
Amaya Duta, Jalan Kuching, Kuala Lumpur Geotechnical Consultancy Services
New Coal Stockyard Area at Tanjung Bin Power Plant, Pontian, Johor Geotechnical Assessment
Proposed Development at Mukim Rantau, Seremban, Negeri Sembilan Civil and Geotechnical Engineering Consultancy Services for Overall Civil Infrastructural Planning and Design
Eco Marina, Batu Kawan, Penang Geotechnical & Maritime Engineering Consultancy Services for Reclamation
Independent Foundation Review of KL118, Kuala Lumpur Geotechnical Investigation of Construction Bored Piles (137 Numbers)
Proposed Investigation Around Karpal Singh Drive Road and the Spring Geotechnical Investigation of Settlement and Remedial Works Design for the Platform
Due Diligence Appraisal Study for Land Acquisition at Non-Aeronautical Area, Kuala Lumpur International Airport (KLIA) Due Diligence Study
Rest And Service Areas- Phase 1 (Basic Amenities And Facilities) For The Jambatan Sultan Abdul Halim Mu’Azam Shah Independent Checking Engineers (Accredited Checkers) for Geotechnical & Structures
Independent Inspection of Cracks at Vivacity Mega Mall, Tabuan Jaya, Kuching, Sarawak Independent Inspection of ‘Cracks’ and “Cracklines’ at Movement Joints
E3: Lebuhraya Laluan Kedua Malaysia-Singapura (Afiat Health Park, Nusajaya, Johor) Independent Check Consultant (Geotechnical)
I-Parc Tanjung Pelepas, Johor Geotechnical Investigation into Earthworks issues
Proposed Mixed Development on Lot 8596, 9514 & 9515 at Tanjung Karang, Kuala Selangor Ground Treatment design for infrastructure works
Investigation Of Collapsed Type 3 Reinforced Concrete (RC) Wall and Review of Existing and Newly Proposed RC Wall (Type 1 – 4) for Hillpark Shah Alam, Daerah Kuala Selangor, Selangor Failure Investigation and Independent Design Review of One Row of Retaining Wall (Type 1 – 4)
Cadangan Kerja Tanah Di Atas Lot 1022, 1023 & Lot 1779, Jalan Teluk Tempoyak, Mukim 12, Batu Maung, Daerah Barat Daya, Pulau Pinang Untuk Tetuan Vienna Home Sdn Bhd Geotechnical Investigation into Extra ROCK Excavation Volume
Review of Tanjong 12, Daerah Kuala Langat, Selangor Ground Treatment Design for Phase 1 (At Grade Section)
Service Apartments at Part of Plot PT 26768, Mukim Batu, KL Geotechnical Consultancy Service
Proposed 3 Blocks of Affordable Apartments at Batu Ferringhi, Penang Geotechnical Value Engineering
Plaza Phoenix Station Layby Facilities Geotechnical Consultancy Service for Slopes, Retaining Walls and Foundation
Proposed Development at Section 7, Shah Alam Geotechnical Consultancy Services
Foundation for 24 Units Shop Lots at Nilai Impian Phase 58 (NI58) Foundation Design
Cut Slope At Lot PT 33484, Mukim Rawang, Daerah Gombak, Selangor Investigation and Remedial Works for Lawsuit
Audit Report for PLUS Highway (Syabas) Geotechnical Checker / Audit Report
Proposed Oxley Towers, KLCC, Jalan Ampang, KL Alternative Foundation and Retaining Wall Design
AEON Maluri Project, Jalan Jejaka, Cheras Dalam Bandaraya Kuala Lumpur Full Geotechnical Consultancy Service
Cadangan Pembangunan 2 Block Bangunan Pangsapuri Perkhidmatan 38 Tingkat FASA 1A, Jalan Segambut, Kuala Lumpur Alternative Foundation Design Consultancy
Proposed Tod Development @ LRT Station 6, Puchong Jaya, Selangor Civil & Structural, Geotechnical and Mechanical & Electrical Consultancy Services
Pembinaan Loji Rawatan Kumbahan Serantau Batu, Jinjang Kepong, Kuala Lumpur Geotechnical Review on Deep Excavation
Elmina Green Phase EG4 & EG5 Foundation Design
Highrise with 3 level Basement, Bukit Ayun, Penang Full Geotechnical Consultancy for Highrise Towers with 3-levels Basement
Proposed Sandakan POIC Jetty, Sabah Expert Advise and Review for Pile Foundation
Geotechnical Consultancy Services for Upgrading B18 (Jalan Bangi Lama) Adjacent to the proposed Development of Serene Heights, Semenyih, Selangor Full Geotechnical Consultancy Services
Mixed Development at Persiaran Barat Section 52, Petaling Jaya, Selangor Scope (A) – Building Inspection (MPC Building Only). Scope (B) – Geotechnical Review of Existing Retaining Wall Adjacent to Hotel Singgahsana and MPC Building Only. Scope (C) – Geotechnical Review of Remedial Measures to Stabilise Existing Retaining Wall Adjacent to Hotel Singgahsana and MPC Building Only.
Bukit Bintang City Centre, Kuala Lumpur Geotechnical Checker & Value Engineering
Geological Assessment for the Linggi Bunded Storage Geological Assessment on Pond Foundation
Promenade: Proposed Beach Terrace, Nusajaya, Johor Geotechnical Consultancy Services for Retaining Wall and Reclamation of Platform of Proposed Artifical Beach Terrace
Apartments at Bukit Baru, Melaka Alternative Foundation Design Consultancy
Tailing Dam Engineering for Tawau Gold Mine Engineering Consultancy Services on Tailing Dam Design for Operational Tailing Storage (for Special Environmental Impact Assessment)
Setiakasih – Proposed High End Residential Project in Damansara Heights, Kuala Lumpur Full Geotechnical Consultancy Services
Geotechnical Support for Preliminary SI for KL Metropolis – Site 5A Geotechnical Support for Preliminary Soil Investigation
Artificial Beach at the Water Garden Promenade, Puteri Harbour, Iskandar Puteri, Johor Geotechnical Consultancy Services for Retaining Wall and Reclamation of Platform of Proposed Artificial Beach Terrace
Foundation Design for 2.3km Sewer Line, Lingkaran Cassia Barat, Batu Kawan, Pulau Pinang Foundation Design for 2.3km Sewer Line
Mixed Development on Lot 76354, Permatang Gaharu, Kawasan Sg. Soi/Sg. Belat, Bunut Rendang, Mukim Kuala Kuantan, Daerah Kuantan, Pahang Geotechnical Design Review
Proposed CP1 (PT 71419) at Jade Hills Geotechnical Consultancy Services for Shop lots
Proposed CP6 (PT 71606) at Jade Hills Geotechnical Consultancy Services for Shop lots
Proposed Condominium Development on Lot 2357, Mont’ Kiara, Mukim Batu, Kuala Lumpur (MK27) Full Geotechnical Consultancy Service
Proposed Residential Development at Puchong Kinrara, Mukim Petaling, Kuala Lumpur Full Geotechnical Consultancy Service
Nilai Impian 2 – SME Business Park Full Geotechnical Consultancy Service
Proposed Residential Development Which Consists of One Tower Affordable Housing, One Tower Medium Range Housing and Podium Carpark at Lot 3582 ABD 3583, Mukim 18, Daerah Timur Laut, Pulau Pinang (FETTES PARK) Civil & Structural and Geotechnical Consultancy Services
Cadangan Pembangunan Bercampur dan Pembangunan Skim ‘Gated Community’ Di Bawah Seksyen 6(A) AKTA 318 (AKTA Hakmilik Strata 1985) Di Atas Lot 1990, 1996, 25301 & 25310, Mukim Semenyih, Daerah Hulu Langat, Selangor Geotechnical Review for Earthworks
Taman Danau Desa Condominium (SkyWorld Development) Full Geotechnical Consultancy Service
Full Geotechnical Service for KL Metropolis – Site 5A Full Geotechnical Consultancy Service
Development for Two Blocks of 50-Storey High Building on Proposed Site with Existing Telekom Building Full Geotechnical Consultancy Service
SPJ Pan Borneo Project from Serian to Pantu (75KM) Geotechnical Review and Alternative Geotechnical Design
Double Track Project from Gemas to Kluang (From Gemas Station to Kluang Station, Approx Imately 107KM) Conceptual Geotechnical Design with Value Engineering
Proposed Penang SRS Preliminary Update and Review of Geotechnical & Maritime Engineering Consultancy Services for Reclamation

2011

Project Name Scope
Detailed Design Of Jambuk Estate Flood Mitigation Project Detailed Design of Flood Mitigation Measures for Jambuk Estate

2010

Project Name Scope
Lot 30351, Mukim Setapak, KL Fee Proposal for Geotechnical, Infrastructure & Structural Engineering Consulting Services
Proposed Pantai Hillpark Phase 7 Geological Site Terrain Mapping Report
Engagement Of Specialist Collaborator To Carry Out Catchment Modelling and Sediment Impact Assessment For Chenderoh Lake Sediment Impact to Chenderoh Dam
Proposed Improvement Works to Alleviate Softground Problems (mushroom) between KM56.70-K56.15 (North Bound) KM56.15-KM55.40 (North Bound) & KM56.15-KM55.40 (South Bound) along Alor Setar to Sg. Petani Expressway, Section N2 The Analysis, Design and Supervision of the Proposed Improvement Works to Alleviate Softground Problem at KM55.40 – KM56.70 (Both Bounds) Section N2
Proposed Commercial Development on 4.31 ac in Setiawan, Perak. Local Infrastructure, Structural and Geotechnical Consultancy Services.
Proposed Petrol Station at Bentong, Pahang Full Civil, Structural and Geotechnical Consultancy Services
German Embassy in Kuala Lumpur Civil & Structural and Geotechnical Consultancy Services
Proposed mixed dev. (Kajang Boulevard) on Lot 462 & 463, Bdr. Kajang, Daerah Hulu Langat, Selangor Geotechnical Review for Foundation System & Full Geotechnical Consultancy for Earth Retaining System
Cadangan Membina dan Menyiapkan Blok Wanita dan Kanak-Kanak dan Pusat Kardiology Hospital Raja Permaisuri Bainon, Perak Civil & Structural Engineering Consultancy Service
Soil Slopes at Sector E, Perdana Parkcity Design of Slope Strengthening Works for Soil Slopes in Sector E (~400m long slopes besides the ‘Amelia’ Development) with Reinforced Soil Wall Loading
Investigation and Monitoring of Failed Slope at Seremban, Negeri Sembilan Geotechnical Consultancy Service for Geotechnical Investigation and Instrumentation Monitoring
Review of Sectors B & D, Perdana Parkcity Independent Geotechnical Review of Rock and Soil Slopes and Existing Rubber Wall Stability in Sector B and Sector D of Parkcity Heights
Proposed Residential Development on 33.37 acres land at Lot 64487, Taman Equine, Mukim Petaling, Daerah Petaling, Selangor Full Geotechnical Consultancy Services
Proposed Coal Mining (Coal Extraction and Transportation) and Rehabilitation of Mined Out Area at BC3 at Mulok (West) at Bukit Dinding, Mukah Full Geotechnical Consultancy Service for Earth Filled Bund for Peat Retention
Proposed development at Jalan Robertson (2.942ac), Kuala Lumpur Full Geotechnical Engineering Consultancy
Alternative Design for Sultan Yahya Bridge, Kelantan Alternative Foundation Design
Geotechnical Inspection of Bungalow in Bukit Bandaraya, Kuala Lumpur Independent Geotechnical Investigation
Independent Geotechnical Review of Existing Rubble Wall Stability in P5 of Parkcity Heights Independent Geotechnical Review of Existing Rubble Wall Stability in P5 of Parkcity Heights
Expert Opinion on 13-Storey Building in Ampang Expert Opinion & Witness
Sheet Pile Quay Wall for The Materials Off Load Facility (MOLF) at Sabah Oil & Gas Terminal Project (SOGT) Alternative Geotechnical Design
HDPE Submarine Pipe Crossing at Batang Paloh, Bahagian Mukah, Sarawak Full Consultancy for Analaysis, Design and Supervision of Submarine Pipeline & Ancillaries Works
Cadangan Pembangunan Sebuh Kompleks Perniagaan 2 Tingkat (Hypermarket) di atas Lot 16051, Mukim Sitiawan, Daerah Manjung, Perak untuk Tetuan Tesco Stores (M) Sdn Bhd Alternative Foundation Design
Cadangan Pembinaan Ibu Pejabat Jabatan Bomba & Penyelamat Malaysia di Wilayah Persekutuan, Putrajaya Alternative Geotechnical Design using Jack-in Spun Piles
Proposed Rehabilitation and Upgrading of Tambunan – Ranau Road Full Geotechnical Design
MK 22 on Lots 1891 & 1892 Geotechnical Consultancy Service
LEKAS Expressway, Kedah Independent Geotechnical Engineering Checking
Lebuhraya Damansara Puchong – Proposed Enhancement Alternative Bridge Foundation and Ground Treatment Design Approach Embankments
Slope protection advisory services – Land at Mukim Jesselton, Kota Kinabalu, Sabah Slope Protection Advisory & Consultancy Services
Strengthening Works of RE Wall, Seksyen 7, Shah Alam, Selangor Investigation and Remedial Works Design for RE Wall & Slopes
Proposed Setia City Mall Alternative Geotechnical Design of Foundation System
Investigation into Slope Movement at Kawasan Perindustrian Rembia, Mukim Sg. Petai, Melaka Geotechnical Investigation and Remedial Design of Slope Movement
Proposed Housing Development on Lot 1116, Mukim Dengkil, District of Sepang, Selangor Full Engineering Consultancy Services
Hillsite Development in Mukim Bentong, Daerah Bentong, Pahang Darul Makmur (Boga Valley) Full Geotechnical Consultancy
Membina Jambatan Kedua Sultan Yahya Petra, Kota Bharu, Kelantan Geotechnical Review on Effect of Adjacent Piling Works on the Existing Bridge, Monitoring Scheme and Protection of the Foundation of Existing Bridge
Media City Engineering Consultancy Services (One-Stop)
Proposed Developments at Seksyen 2, Bandar Batu Feringghi, D.T.L. Pulau Pinang Rock Slope Mapping and Strengthening Works for a section of 60m and 8m High Rock Slope
Investigation into Vibration Problems at Mont Kiara Geotechnical Assessment of vibration
Mixed Housing Development at Mukim Ampang, Daerah Hulu Langat Full Geotechnical Consultancy
Proposed Development of new LCCT & Associated works at KLIA, Sepang, Selangor Geotechnical Advice for LCCT Package 2 Earthworks
Integrated Environmental Monitoring Plan (IEMP) of Lojing, Kelantan Full Geotechnical Engineering Consultancy
Geotechnical Assessment of Vibrations at N4-ROB2 (Jalan Berapit) Geotechnical Assessment of Vibrations at N4-ROB2 (Berapit)
Engineering Consultancy Services for Ulu Jelai & Ulu Terengganu Hydroelectric Full Engineering Consultancy for Civil & Structures, Geotechnical, Hydrology and Hydraulic Engineering Works
Proposed Mixed Development Project in Damansara Uptown – Phase II Full Geotechnical Engineering Consultancy
Kota Bunyi Tailings Dam – Klian Intan Mine Full Engineering Consultancy Services for Raising Kota Bunyi Tailings Dam by 10m
3-Storey Shop Lots at Mukim Cheras, Selangor Local Infrastructure, Structural and Geotechnical Consultancy Services

2009

Project Name Scope
Bund Stability, Seepage, Buoyancy for a Basement Excavation at Putrajaya Maritme Centre Expert Witness & Arbitration
Slope Rehabilitation Works at KM30.4 NB (Linkedua) & KM 18.4 NB (NSE) Geotechnical Consultancy Service
Cribwall & Slope at Taman Bukit Mewah, Kajang, Selangor Geotechnical Investigation and Strengthening Design
Pantai Panorama Condominium, Kuala Lumpur Site Inspection & Independent Geotechnical Advice
Cadangan Menaiktaraf Jalan Dari Persimpangan Bunga Chengkih Ke Persimpangan Lrpt Ke Sg Lembing (C04), Kuantan, Pahang Independent Review of Ground Treatment Design
Wisma Prima at Jalan Sri Semanthan, Damansara Heights, Kuala Lumpur Independent Geotechnical Review & Strengthening Works
Site Clearance, Earthworks, Retaining Walls and Drainage Work, Mukim Petaling, Daerah Petaling, Selangor (Arch Culvert) Geotechnical Investigation into Cracked and Culvert
Pelangi Semenyih Phase 3, Selangor Geotechnical Investigation & Remedial Works Design
Shell Bagan Luar Tank Installation Geotechnical Consultancy Service
High Risk Slopes at KM 28.40 (Southbound) and KM30.00 (Southbound) of the Linkedua Expressway Geotechnical Consultancy Service
Site Inspection at Parkcity Heights Geotechnical Review of Slope Stability
Geotechnical Investigation & Remedial Works at Taman Bukit Segar Geotechnical Consultancy For Strengthening and Remedial Works
Proposed Commercial Development on Lot PT 118177 Hakmilik H.S.(D) 126732, Bandar Botanic, Mukim Klang Daerah Klang Selangor Darul Ehsan Alternative Geotechnical Design
Cracks at Brick Wall at the Residence Abutting I-Zen Geotechnical Inspection and Opinion on Retaining Structures
Water Supply in Lanchang, Pahang Geotechnical Consultancy Services
Proposed Yen So Development at Hoang Mai District, Hanoi, Vietnam Geotechnical Consultancy Services
Proposed Mixed Development on Lot 2319 Mukim Beranang, Daerah Hulu Langat, Selangor Geotechnical Consultancy Services
Geotechnical Inspection at Aman Sari 18 Development on Lot PT 50, Mukim Petaling, Daerah Petaling, Selangor Darul Ehsan for Messrs. Prestij Permai Sdn Bhd Geotechnical Investigation & Remedial Works Design
Pump Station at Sunggala, Port Dickson, Negeri Sembilan Independent Geotechnical Review of Temporary Sheet Pile Design
Foundation Design for RS Wall & RC Design for RC Capping for Bandar Sungai Pusu, Setapak Geotechnical Consultancy for Design for RE Wall Foundation & RC
Coping
40 Storey Apartment at Jalan Tun Razak / Jalan Raja Muda Abdul Aziz, Kuala Lumpur Alternative Geotechnical Design of Foundation System for Podium
Failure of Buildings at Bukit Cherakah, Shah Alam, Selangor Expert Witness
Alternative Foundation Design for 4 Apartments, Mukim Sg. Buloh, Daerah Petaling Alternative Geotechnical Design of Foundation System
Landslide at Wangsa 1, Bukit Antarabangsa, Ampang, Selangor Geotechnical Investigation & Remedial Works Design
Mixed Development at Precint 10 and 12, Shah Alam Geotechnical & Geological Consultancy Service for Geological Mapping and Stability Analysis
Proposed Mixed Development Project in Damansara Uptown – Phase II Geotechnical Review Consultancy Service
Proposed Slope Rehabilitation Works at KM30.4 NB (Linkedua) Geotechnical Consultancy Service
Proposed Construction of Hydrocarbon Storage and Distribution Facility at Tanjung Bin, Johore Geotechnical & Maritime Engineering Consultancy Services for the Reclamation Works
Bungalow of Dato Seri Dr. Wong Yeon Chai at Taman Duta Geotechnical Inspection Report
Penang Island Bay Resort Concept to Full Geotechnical Consultancy Service
Cadangan Pelan Jalan Dan Peparitan Di Atas Lot 29 (PT 24374), Mukim Setul, Daerah Seremban, Negeri Seremban Expert Withness & Geotechnical Investigation into Wall Failure
Geotechnical Design for Slopes & Retaining Structures of Taiping Portal (Double Track) Geotechnical Design of Slopes and Retaining Structures
Proposed Geotechnical Consultancy Services For Slope Stability Of A9 Road (Ch775 To Ch1268) And Ppu At Damansara Perdana Geotechnical Consultancy Services
Advice on Foundation on Bus Terminal at Bandar Tasik Selatan Geotechnical Alternative Design of the Slip Roads 3 & 4
Perdana Parkcity – Design of Soil & Rock Slopes in Sector C & E Design of Soil & Rock Slope Strengthening Works in Sector C & E
Geotechnical Investigation & Remedial Works for the Bungalow of Dato Seri Dr. Wong Yeon Chai at Taman Duta, 50480 Kuala Lumpur Geotechnical Investigation & Design of Remedial Works for Reinforced Soil Walls (Three Sides) & Raising of the Platform at One Side of the Wall
Econpile Kenangan Wholesale City CBP Wall Collapse & Third Party Damage At Jalan Merlimau, Kuala Lumpur Independent Geotechnical Investigation
Mayfair Basement 5, Penang Geotechnical Advice on Leakage/Seepage of Basement
Housing Development at Taman Desa, Kuala Lumpur Independent Geotechnical Review Report  (ICE Report for DBKL)
15 Bungalows at the Peak, Taman TAR Geotechnical Engineering Consultancy Service For Hill Site
Commercial Development at Lot 38289, Jalan SS6/3, Bandar Petaling Jaya (Jack In Spun Piles Alternative Design) Full Alternative Geotechnical Design using Jack-in Spun Piles
Geotechnical Inspection into building cracks at Kota Malim Prima, 35900 Tanjung Malaim, Perak Darul Ridzuan Geotechnical Inspection and Investigation
Proposed Commercial Development On Lot Pt 118177 Hakmilik H.S.(D) 126732 Bandar Botanic, Mukim Klang, Daerah Klang, Selangor Darul Ehsan (Phase 2) Geotechnical, Structural and local Infrastructure Engineering Consultancy Services
Projek Pembaikan Cerun-Cerun Jalan Tamparuli-Ranau KM79, Sabah Sub-Consultancy Agreement on Slope Rehabilitation Work
Earthworks contract for building & parking – LCCT Extension Full Geotechnical Consultancy Service for Earthworks & Ground Improvement Works
Investigation on Slope Erosion at Pulau Gaya, Sabah Consultancy Service for Geotechnical Investigation & Overall Slope Stability Assessment & Remedy Works for Three Failed Slopes
Cadangan pembangunan 2 blok pejabat industri 9 tingkat di atas 7 tingkat podium pejabat industri, ruang pameran, tempat meletak kenderaan & kemudahan awam di atas Lot 76 Jln. Semangat, Seksyen 13 Petaling Jaya, Selangor untuk Plaza 33 Sdn Bhd Alternative Geotechnical Design using Jack-in Spun Piles
Residents Appeal on Tan Jit Seng, Penang Geotechnical Review on Analysis & Design of Hillsite Development Adjacent to Solok Tan Jit Seng
Expert Witness on Embankment Failure in Bandar Puncak Alam, Selangoror Expert Witness
Investigation into Failure of 100m Road Beside Setia City Mall (66ft Haul Road at Precint 1, Hummock Estate, Bukit Raja) Geotechnical Review of the Remedial Works
 Collapse of boundary in Taman Bukit Pantai, Kuala Lumpur  Independent Geotechnical Advice
 Plot 7, Sepang Gold Coast  Value Engineering Consultancy Service
 The Extraction, Transportation and Rehabilitation of Coal at Area BC1-B with Extension to BC1-C, Ulu Sikat, Mukah, Sarawak  Geotechnical Investigation into Bund Failure
 MK 20 Commercial Development  Full Gotechnical Consultancy Service
 Two 24 Storey Condominium with 3 Storey Carpark, Taman Gembira, Kuala Lumpur.  Foundation Design of Condominium and Carpark
Investigation of Pipe Support Movements at Eastern Bank of Sg. Buloh of Johore Port, Johore Revised Consultancy Proposal
Expert Opinion on Viability of Dynamic Compaction Method at Lots 1217, 1218, 1225, 1226 & 1227, Mukim Hulu Kelang, Daerah Gombak, Selangor Expert Opinion on Vaability of Dynamic Compaction Method
Pangkor Laut Second Home Preliminary Geotechnical Consultancy Service for EIA
Independent Geotechnical Review in Sectors B & C in Desa Parkcity Independent Geotechnical Review of Slopes Stability
Mixed development at Kajang (K24 & K25) Full Geotechnical Engineering Consultancy Services for Infrastructures works for New Lyout & Foundation for Buildings.
Proposed 1 Block of 24-Storey Apartment And 1 Block of 24-Storey SOHO at Equine Park for Naza TTDI Civil & Structural Consultant
Gated Community of Bungalow & Semi-Deteched Houses at Mukim Hulu Klang, Daerah Gombak Alternative Geotechnical Consultancy Services for the 18 units of Bungalows, 6 units of Semi-Deteched Houses & Perimeter RC Retaining Wall (Section 3)
Investigation into the soil nailed slope failure at Maktab Rendah Sains MARA, Bentong, Pahang Geotechnical Investigation into the causes of the Landslide
Mengkuang Dam Extension, Pulau Pinang Full Geotechnical Consultancy Services for Temporary Cofferdam, Tunnel Portal & Advise on Grouting Works
Proposed Geotechnical Consutancy Service for Basement and Foundation for Phase I & II of Platinum Park Chronological Event of G&P’s Consultancy involvement in Platinum Park
Geotechnical Review of Foundation & Basement Works at Lot 248, Off Jalan Ampang, Kuala Lumpur Independent Geotechnical Review & Full Geotechnical Consultancy Services with Value Engineering
Jesselton Hills at Kota Kinabalu, Sabah C&S, Quantity Surveying & Geotechnical Engineering Consultancy Services for Main Infrastructure Works
Permohonan Kebenaran Merancang bagi tujuan tukar syarat secara serentak di bawah Seksyen 124A Kanun Tanah Negara di atas Lot 1336, 1337, 1338 & 1339 Mukim Rawang, Daerah Gombak, Selangor untuk Tetuan Rentak Arena Development Sdn Bhd Independent Geotechnical Review Report
Proposed Saiwai Land Tower, Lorong Yap Kwan Seng, Kuala Lumpur Structural (included MASMA Submission) & Geotechnical Consultancy Services
Proposed 690 Units Condominium at Parcel C Armanee Terrace, Damansara Perdana Full Geotechnical Engineering Consultancy Services
2 Blocks of 19-storey condominium with 4 levels of carpark at Mukim Cheras, Kuala Lumpur Alternative Geotechnical Design for the Foundations
 Proposed Geotechnical Consultancy Services For Slope Stability Of A9 Road (Ch775 To Ch1268) And Ppu At Damansara Perdana  Geotechnical Consultancy Services
 Proposed 2nd Bridge Load Out Jetty at Batu Kawan, Penang – Investigation into the pile damage  Geotechnical Investigation Into A Pile Damage
 Advice on Foundation on Bus Terminal at Bandar Tasik Selatan  Geotechnical Design of the Slip Roads 3 & 4
 Perdana Parkcity – Design of Soil & Rock Slopes in Sector C & E  Design of Soil & Rock Slope Strengthening Works in Sector C & E
Geotechnical Investigation & Remedial Works for the Bungalow of Dato Seri Dr. Wong Yeon Chai at Taman Duta, 50480 Kuala Lumpur Geotechnical Investigation & Design of Remedial Works for Reinforced Soil Walls (Three Sides) & Raising of the Platform at One Side of the Wall
Econpile Kenangan Wholesale City Cbp Wall Collapse & Third Party Damage At Jalan Merlimau, Kuala Lumpur Independent Geotechnical Investigation
Mixed development at Kajang (K24 & K25) Full Geotechnical Engineering Consultancy Services for Infrastructures works for New Lyout & Foundation for Buildings.
Proposed 1 Block of 24-Storey Apartment And 1 Block of 24-Storey SOHO at Equine Park for Naza TTDI Civil & Structural Consultant
Gated Community of Bungalow & Semi-Deteched Houses at Mukim Hulu Klang, Daerah Gombak Alternative Geotechnical Consultancy Services for the 18 units of Bungalows, 6 units of Semi-Deteched Houses & Perimeter RC Retaining Wall (Section 3)
Proposed Geotechnical Consutancy Service for Basement and Foundation for Phase I & II of Platinum Park Chronological Event of G&P’s Consultancy involvement in Platinum Park
Jesselton Hills at Kota Kinabalu, Sabah C&S, Quantity Surveying & Geotechnical Engineering Consultancy Services for Main Infrastructure Works
Permohonan Kebenaran Merancang bagi tujuan tukar syarat secara serentak di bawah Seksyen 124A Kanun Tanah Negara di atas Lot 1336, 1337, 1338 & 1339 Mukim Rawang, Daerah Gombak, Selangor untuk Tetuan Rentak Arena Development Sdn Bhd Independent Geotechnical Review Report
Proposed Saiwai Land Tower, Lorong Yap Kwan Seng, Kuala Lumpur Structural (included MASMA Submission) & Geotechnical Consultancy Services
Proposed 690 Units Condominium at Parcel C Armanee Terrace, Damansara Perdana Full Geotechnical Engineering Consultancy Services
2 Blocks of 19-storey condominium with 4 levels of carpark at Mukim Cheras, Kuala Lumpur Alternative Geotechnical Design for the Foundations

2008

Project Name Scope
Proposed Development of Double Storey Research and Development Center at Lot 471, Mukim Temenggor , Daerah Hulu Perak, Perak Darul Ridzuan For Messrs M.K.N. Group Sdn Bhd
Slope Failure Investigation at UKM
Proposed Commercial Development on Lot 1881 and 1882, Kuala Lumpur – MK 20
Proposed Service Apartments at Jalan Pahang, Seksyen 47, Kuala Lumpur
Proposed Mixed Commercial Development of Solaris 3 on a 18.75 Acres Land Comprises of Office Blocks, Serviced Apartments & Hotel, Shop Offices, Retail Spaces with Overhead Retail Link Bridge to Neighbouring Development & Basement Carpark
Failure of Retaining Wall at Factory Lot in Kuala Lumpur
Collapse of Part Adjoining Wall, Oakland Industrial Park, Seremban, Negeri Sembilan Geotechnical Investigation & Advice
Development on Lots 54542-54555, Mukim of Kuala Lumpur, Wilayah Persekutuan Geotechnical Consultancy Services
Reclamation at Gurney Drive, Penang Geotechnical Consultancy Services
Sepang  Distribution Centre Geotechnical Consultancy Services
Slope Failure at Boundary of Taman TAR 2 Project Site, Lot 11639 Geotechnical Investigation & Remedial Works
Redevelopment At Jalan 225,Sungai Way,Petaling Jaya Geotechnical Consultancy Services
Sink Hole & Depression Areas Along Transition Between Terminal Yard and Berth Area from Berth 7 to Berth 10 (Phase II) Geotechnical Consultancy Services
Foundation Strengthening Works for Wisma Matex, Johor Bahru, Johor Geotechnical Review Consultancy on Foundation Strengthening Design
Inspection & Expert Opinion for Lot 10932-10936, 10939-10944 & part of Lot 10916 & 13100 Mukim Gali, Daerah Raub, Pahang Geotechnical Site Inspection & Expert Opinion
Wisma Prima at Jalan Semanthan, Damansara Heights, Kuala Lumpur Geotechnical Review & Geotechnical Site Inspection
Pulau Indah Ring Road Geotechnical Consultancy Services Supporting Lead Consultant
Puan Sri’s House at Bukit Tunku, Kuala Lumpur Geotechnical Consultancy Services
Bridge Foundation at Kg. Melayu Subang, Daerah  Petaling, Selangor Alternative Design of Bridge Foundation
Landslides at Bukit Antarabangsa Geotechnical Consultancy Services
Independent Geotechnical Review and Remedial Works for TTDI Hills Development Geotechnical Investigation, Review and Remedial Works
Defects & Damages at Block G of Petronas Research & Scientific Services Sdn Bhd Geotechnical Consultancy Services
Highrise Development Condominium at Setapak, Kuala Lumpur Independent Geotechncal Review of Foundation
Arbitration between Dewan Perniagaan Melayu Malaysia Kuala Lumpur vs Government of Malaysia Expert Witness & Arbitration
Landslip at Lot 1596, Geran 49811, UK Heights, Ulu Klang, Selangor Geotechnical Consultancy Services for Slope Strengthening Works
Vila Sri Ukay, 6 ¼  Mile, Hulu Kelang, 68000 Ampang, Daerah Gombak, Selangor Geotechnical Site Inspection

2007

Project Name Scope
Dam monitoring at Putrajaya Geotechnical Advise on monitoring results
Proposed Immediate Works to cut slope failure at KM30.0 NB, Linkedua Expressway Geotechnical Consultancy for the investigation and design of remedial works for the failed slopes
Investigation on Wall Collapse Investigation of wall failure
Consultancy Services for remedial works of slope failure at ML 119, Segamat Regional Office, PGB-TOD Slope Failure and remedial design
Proposed Rehabilitation of Slopes at North South Expressway (Linkedua KM19.3NB) Geotechnical Consultancy for the investigation and design of remedial works for the failed slopes
Slope and failure related to project Jalanraya Simpang Pulai-Lojing-Gua Musang-Kuala Berang along the proposed road for Aring to Jambatan Pasir Pulau, Terengganu Second opinion on Failed Slope Investigation
Geotechnical investigation and remedial work for the collapsed slope at existing water tank, Taman Bukit Kepayang Phase M, Negeri Sembilan Investigation of slope failure & remedial work
Cadangan Pelan Susunatur Pembangunan Perumahan Dan Perniagaan Di Atas Lot 1116 (Tanah Pemberimilikan Kerajaan), Mukim Dengkil, Daerah Sepang, Selangor Darul Ehsan Full Geotechnical Consultancy for Pond Reclamation
Proposed Development of Hijauan Cheras Full scope consultancy for Hill-Site Development
Geotechnical Review of All Wall Types on Lots PT 5425 (Parcel E) & PT 5427 (Parcel F), Bukit Segar, Kuala Lumpur Geotechnical review of Retaining wall stability
Expert Opinion on the Failure of the Box Culvert Expert opinion on failure of box-culverts
Kerja-Kerja Cerucuk and Sub-Struktur untuk Cadangan Pembangunan di atas Lot 29510, Jalan Tun Mohd Fuad //Jalan Tun Mohd Fuad 4, Mukim Kuala Lumpur, Wilayah Persekutuan Alternative foundation design
Cadangan Pembangunan 33 Unit Rumah Teres dan 94 Unit Rumah Berkembar 2 tingkat di atas Lot 188, Mukim Cheras, Daerah Hulu Langat, Selangor Darul Ehsan untuk Tetuan Regal Form Sdn Bhd Geotechnical Consultancy for Hill-Site Development
Geotechnical review of mosque at Pangkalan Tentera Udara Diraja Malaysia Sungai Besi Mukim Bandar Kuala Lumpur Geotechnical Review of foundation
Proposed Tengah Garden, Langkawi For Anders Hagstorm, Richard Curtis and Narelle Full Geotechnical Consultancy for Residential  Development
Certification and Supervision of Construction of KM32.6SB Geotechnical Consultancy for the investigation and design of remedial works for the failed slopes
Mixed Development on Lot 1352,1402,1403,1404,1406,1684,1408,1409,1410 & 1411 at Kajang Silk Highway (SunwayMas S/B) Full scope consultancy for Hill-Site Development
Port of Ehoala, Madagascar (Geotechnical Review & Secondment of Site Geotechnical Engineering) Geotechnical Review of Quay Wall
Cadangan Pembangunan (Fasa 2) Perumahan di atas Lot 2259, Mukim Kajang, Dearah Hulu Langat, Selangor (D-Hill S/B) Geotechnical Review for Hill-Site Development
Upgrading Works of Keningau-Kimanis Road, Sabah – Slope Failure, Depression to Road Pavement and Drains, Cracked/Tilting to Reinforced Concrete Wall Investigation at CH42+125 to CH42+300 Geotechnical Investigation On Slope Instability And Distressed Retaining Wall
Proposed 16 Storey Office Wwith 3 levels of Bbasement in Subang Jaya Review For Basement Excavation
Investigation into the tilting of driven piles at Dataran Pahlawan Phase II Melaka Investigation Into The Tilting Of Piles During Excavation For Pilecap
Design, Construction and Installation of 40,000 Ton Loadout Tracks and Associated Works for Malaysia Marine and Heavy Engineering Sdn Bhd, Pasir Gudang, Johor Full Civil & Geotechnical Consultancy Services
Alternative design for Cadangan pembangunan 3 blok pangsapuri 43 tingkat at Lot 451, Seksyen 67, Jalan Kiara 1, Kuala Lumpur Alternative Foundation Design For Value Engineering
Proposed Highrise Condominium At Jalan Kurau, Bangsar, Kuala Lumpur Full Geotechnical Consultancy For Residential Condominium With Basement At Hill Site
Remedial Design For Retaining Walls At Parcel E & F Of Bukit Segar, Cheras, Kuala Lumpur  Geotechnical Review And Remedial Solution For Slopes And Walls
Proposed Mixed Development on Approximately 366 Acres at Kajang Height, Selangor-Access Road From Silk Highway Geotechnical Consultancy Service For Wall, Slope And Bridge Foundation Of Road Project
Cadangan Pembangunan Perdagangan di atas Lot 1883 & 1884 Jalan Mon’t Kiara, Mukim Batu, Kuala Lumpur Full Geotechnical Consultancy For Highrise Development With Deep Basement
Proposed 1 Block Of 33 Storey (103 Units) Condominium At Lot 100 & 101, Seksyen 43, Persiaran Lidcol, Off Jalan Yap Kwan Seng, Wilayah Persekutuan Kuala Lumpur Geotechnical Consultancy Service For Foundation And Basement At Limestone
Kelantan Flood Mitigation Full Engineering Consultancy Services For Flood Mitigation And Maintenance Scheme And Water Quality Improvement
Widening of Penang Bridge Geotechnical Specialist Review Of Foundation Design And Construction
Proposed 100 feet Road & Drainage Works (Masteron Site to Highway) for Infrastructure Cost Sharing Joint Venture Party (JV) on the land to serve the Development for Green Crescent Resources Sdn Bhd, Aspek Analisa Sdn Bhd & HK Land Sdn Bhd Geotechnical Design For Rised RS Wall Embankment
Berembang Ampang New Town Development Project Full Scope Geotechnical Consultancy Service For Highrise On Limestone Foundation
Reinforced Earth Structure 1 at UiTM Project on Lot PT1567 & Lot PT1658, Kumim Jeram, Daerah Kuala Selangor, Selangor Geotechnical Investigation Of Wall Failure And Remedial Works Design
Proposed Second Penang Bridge – Geotechnical Review And Advice on Preliminary Pile Design and Installation Inspection of preliminary test piles and advice
Proposed Development For Hunza Properties (Penang) Sdn Bhd – Alternative Foundation using Spun Piles Alternative foundation design
The Construction and Completion of Main Drainage Works for Pembangunan di atas Lot PTB 20704 HS(D) 257219, Mukim Bandaran, Daerah Johor Bahru, Johor Investigation of failure of culvert
Slope Failure At Raub Investigation into the failure and advice
Cadangan Pembinaan 74 Unit Rumah Teras Dua Tingkat (24’x75′) Diatas Lot PT32564-32637 Dan Sebuah Pencawang Elektrik Diatas Lot PT32563, Fasa 2E, Putra Heights, Mukim Damansara, Daerah Petaling, Selangor Geotechnical design of foundation
Proposed Bungalow Lots with Slope Problem for Parcel E, Bukit Segar, Cheras, Kuala Lumpur Geotechnical design for slope stabilisation retaining wall and foundation for hill side development
Cadangan Pembinaan Rumah Teres Di Fasa 4A (58Unit) and 4B (66 Unit) Di Atas Sebahagian Lot PT20294, USJ Heights, Mukim Damansara, Daerah Petaling, Selangor Geotechnical design of foundation
Redevelopment Of Three Old Bungalows Into Six Bungalows At Ukay Heights, Selangor Geotechnical consultant for hill site development
Kebenaran Merancang Bagi Pertapakan Kepada Bangunan Pulau Banding Resort Sedia Ada, Pulau Banding, KM35.8. Lebuhraya Timur-Barat, Daerag Gerik, Perak Daurl Ridzuan Geotechnical service for hill side development with pond
Proposed Development On Lots 584, 585, & 599, Mukim Ulu Klang, District Of Gombak, Selangor Darul Ehsan  Geotechnical Design For Hill Site Development
North-South Expressway – The Design for the remedial works to alleviate soft ground problems (mushrooming) at KM 46.7 and KM71  Geotechnical Design Of Remedial Works For Soft Ground
Proposed Development Of 1 Block of 20-25 Storey Services Apartment At Desa Melawati  Full Geotechnical Consultancy Services For Highrise
10 Units Of Cooling Towers At ABF Bintulu  Tender Design Of Foundation
Proposed Development At Parcel 1 (H) Of Section 51A, Bandar Petaling Jaya, Selangor Darul Ehsan Design Review Of Foundation And Basement Design
Investigation On Collapse Of Complex Tourism In Pulau Banding, Gerik, Perak Darul Ridzuan Member Of Independent Board Of Inquiry
Proposed One Block Of 50-Storey Office Structure With 6-Storey Podium And 3-Storey Basement (Phase IV, 2.88 Acres) At Seksyen 63, Lorong Stonor, Bandar Kuala Lumpur Untuk Tetuan TTDI Development Sdn Bhd Full Geotechnical Consultancy For Highrise With Basement In Limestone Formation
Design Checker for Storage Tank Foundation at Tanjung Langsat Port, Johor
Development Of Four Bungalows At Bukit Tunku, Kuala Lumpur
Proposed Mixed Development On Approximately 270 Acres At Kajang, Selangor Darul Ehsan
Cadangan Membina & Menyiapkan Bangunan Ibu Pejabat Suruhanjaya Tenaga di atas Lot 2C15, Precinct 2, Daerah Putrajaya, Wilayah Persekutuan Putrajaya
Thach Ban New City, Hanoi, Vietnam
Proposed Development At No. 12, Jalan Kapas, Bangsar, Kuala Lumpur

2006

Project Name Scope
The Proposed 5.4 Acres Office Development at Damansara Perdana Value Engineering option for foundation & retaining walls
Pipebridge Failure at Pulau Indah Investigate failure of pipebridge
Kota Kinabalu Airport Extension Specialist checker
Inspection on the anchored sheetpile at the Makmak Veterinar, Kawasan Selatan Johor Bahru, Johor Review on the safety of anchored sheet pile
Cadangan Kerja Tanah untuk mendirikan 77 unit rumah teres dua tingkat di MK12, Jalan Permatang Damar Laut, DBD, Pulau Pinang Expert advice on the failure of RC Wall
Independent Consultant to Investigate Failure of Retaining Wall for 130 units of Terraced Townhouses at the Sunway Damansara Township in Kota Damansara, Selangor – Independent Geotechnical Investigation Geotechnical investigation of wall failure
Soil Treatment for Boubyan Seaport Project, Kuwait Geotechnical design of ground treatment for highway & railway
Cavity & Sinkholes Treatment & Monitoring of Ixora Apartments – Geotechnical Monitoring Interpretation Report Geotechnical monitoring interpretation of cavity and sinkholes treatment
Proposed development of link houses between Jalan Wangsa 9 & 11, Kuala Lumpur Full Geotechnical Consultant for Hill-Site development
Proposed Hostel for Anak Yatim in Seremban (VOLUNTARY) Full Geotechnical Consultant for Foundation
Cadangan Mendirikan Sebuah Kilang Setingkat Bagi Mengisi Minyak Sawit Di atas Lot 15, Pulau Indah, Klang Full Geotechnical Consultant for foundation
Redevelopment of Sultan Abdul Halim Airport, Alor Setar, Kedah Expert advice for ground treatment of soft ground
Creek Marina Residential Development, Karachi, Pakistan Alternative Foundation Design
Proposed Development in Lot PT 12176 (HS D07812) Block 16, Mukim Dengkil, Daerah Sepang, Selangr Darul Ehsan Full Geotechnical Consultant for foundation
Port Klang Free Zone (PKFZ) – West Port Interchange C&S & Geotechical consultant for interchange
Cadangan Pembangunan Perumahan di atas Lot-lot 62, 63, 961, 2451, 2452, 2140 & 2141 Mukim Kuala Lumpur, W. Persekutuan – Soil Investigation into the Movements of R. Wall Geotechnical investigation on Retaining Wall failure
Cemetery at Semenyih Geological terrain mapping
Proposed Hydragen Plant in West Port Klang, Pulau Indah KLK Oleomas Full C&S, M&E, Goetech Consultancy
Proposed Mixed Development in Damansara Perdana on Lot PT44010, Lot 349, Mukim Sg. Buloh, Petaling Jaya, Selangor Darul Ehsan Geotechnical consultancy for foundation, basement and slope stabilisation work for high rise structure
Proposed Residential & Commercial Development on Lot 4790 Jalan Paya Terubong, Mukim 13, Daerah Timur Laut, Pulau Pinang Geotechnical review of hill-site development
Proposed Residential Development (Cheras 50 acres) on Lot PTD 4595 – 4599, Mukim Ampang, Selangor Full geotechnical consultancy for infrastructure of hill-site
Third Party Rock Slope failure and damage to third party premises @ Talam Construction Site Geotechnical investigation of rock slope failure
Proposed Paper & Pulp Mill at Kunak, Sabah Alternative foundation design for industrial structure and machine foundation
Analysis of Tunnel Adjacent to Pylons Independent analysis of influence of tunnel on Pylons
Commercial Development on Lot 4 and 4A Jalan Utara, Petaling Jaya  Geotechnical consultancy for foundation, basement and slope stabilisation work for high rise structure
Design for the Remedial Works to Alleviate Softground problems at Four Locations North-South Expressway (KM63.8 to KM64.7)  Geotechnical remedial works design for soft ground “mushroom” problem
Review of Exhibition Centre and Flyover at Precinct 5, PKFZ, Pulau Indah (Wijaya)  Review of bridge & roof of exhibition centre
Proposed Trusan Regional Water Supply, Lawas, Limbang Division, Sarawak  Geotechnical design of Tank foundation on soft ground
Proposed Giant Hypermarket at Bandar Sri Permaisuri, Cheras, Kuala Lumpur  Geotechnical consultancy for foundation in mining land
Proposed Mixed Development on Approx. 105.091 acres at Lot 245 G10582, Asiatic Paya Rumput, Melaka Full C&S & Geotechnical for housing development
Proposed Master Plan @ Lot 5798, Mukim of Kuala Kuantan Full C&S & Geotechnical for hill-site development
Proposed Development On 82.44 Acres (Next to Taman Bukit Puchong), Mukim Petaling, Daerah Petaling (Mutiara Indah) Full C&S & Geotech for hill-site development
Independent Checker for Proposed Remedial Works for Mosque in Klang ICE for geotechnical remedial works
Checking of Tunnel Link Inferance on Prestressed Ground Anchor Independent analysis of influence of tunnel on ground anchors of retaining wall
Ground Treatment for South Klang Valley Expressway Geotechnical design of expressway
Cadangan Pembangunan Perdagangan Di Atas P.T. 4043 H.S. (D) 69970 Dam Plot C, Taman Pandan Mesra, Kampung Ampang Campuran, Mukim Ampang, Daerah Hulu Langat, Selangor Untuk Tetuan Keringat Global Development Sdn Bhd Geotechnical consultancy for foundation design at mining land and limestone formation
Proposed Taman Beringin Landfill in Jinjang Utara, Kuala Lumpur Geotechnical consultancy for landfill closure cover design and side slope protection work and alternative foundation design for leachate treatment plant
Cadangan Perumahan Pembangunan Bercampur di atas Tanah seluas 59.30 ekar, Mukim Bukit Raja, Daerah Petaling, Selangor (Geological Terrain Mapping) Geological terrain mapping
Remedial Works for Distressed RC Retaining Wall at Mutiara Seputeh Geotechnical consultancy for remedial work of retaining wall
Proposed Extension of Lumut Jetty Geotechnical consultancy for Jetty Structure
Ground Settlement and Cracks at Wisma Perwira Geotechnical investigation & remedial works for settlement of building due to tunnelling
Slope Masterplan Study Master Plan Study for landslide loss reduction
Design and Supervision of Selected Slopes at KM55.35NB & KM55.60NB, Section S4, along North-South Expressway Geotechnical remedial works design for slopes
Landslip / Subsidence Damage to Building in Lahad Datu, Sabah Investigation of slope movement
Inspection of Embankment Failure at Phase 3B, Bandar Puncak Alam, Selangor Darul Ehsan Inspection
Ukuran Aras dan Butiran, Di Atas Lot 2902 dan PT 675 (Sebahagian Lot 3290), Mukim Kedawang, Daerah Langkawi, Kedah Darulaman Geotechnical consultancy for hill-site development
Chin Swee Caves Temple, Genting Highlands Geotechnical investigation for landslide
Engineering Consultancy Service for Geotechnical for the 1.2 million Gallon on-Ground Water Reservoir and Earthworks (40 Acres) Geotechnical consultancy for hill-site development
Bandar Nusaria Project (Show House) Geotechnical consultancy for hill-site development
Bon Ton Villas, Langkawi Geotechnical consultancy for soft ground engineering
Proposed Offshore Unloading Facilities for Desalination and Power Plants at Shuqaiq, Saudi Arabia Geotechnical consultancy service on marine structure foundation design
Feasibility Study and Preliminary Geotechnical Consultancy for Hillsite Development next to Meru Valley Geotechnical consultancy services for hillsite development
Cadangan Projek Pertanian di atas Lot 451, Mukim Ulu Telom, Cameron Highlands, Pahang Geotechnical consultancy services for hillsite development
Cadangan Pembangunan Dua Blok Pangsapuri Mewah 27 Tingkat dengan Basement di Lot 269 Seksyen 63 Lorong Stonor, Kuala Lumpur Alternative design for basement and foundation construction at limestone area
Proposed Failure Investigation of Wall Collapse Geotechnical investigation and remedial design for distressed basement construction
Cadangan Pembinaan 224 Unit Rumah Teres Satu Tingkat Di Fasa 13E Di Atas Sebahagian Lot 51388, Bandar Bukit Raja, Mukim Kapar, Daerah Klang Utara, Klang Geotechnical consultant for foundation design
Retaining Wall for Taman Desa Tebrau Foundation design for reinforce wall structure at soft ground
Proposed Flood Mitigation and Maintenance Scheme for Lower Klang River, Basin, Selangor Full Geotechnical Consultancy Services
Retaining Wall and Slope Inspection for K24 & K25, Mukim Kajang, Daerah Hulu Langat, Selangor Slope Inspection to comply to JKR requirements
Independent Checker for Excavation of Pit at Mycron Steel combines tension levelling and skin-pass mill line Independent checker for basement excavation
Cadangan Membina 39 Unit Rumah Kediaman Diatas Lot 1423, Mukim Kuala Lumpur, Wilayah Persekutuan (Meru Selekoh) Investigation of stability of wall & slope
Lot 6117 & Part of Jalan Mulia 1/1, Mukim Hulu Kelang, Daerah Gombak, Selangor Full Geotechnical consultancy services for hill site development
Proposed Development for Kota Kemuning Housing Project Full Geotechnical consultancy services for housing development on soft ground
Geotechnical Investigation in Machinery Foundation Settlement for CMS Cement Plant at Bintulu, Sarawak Investigation of settlement of machine foundation.
Proposed Development at Lot 2262, Mukim Kedawang, Daerah Langkawi, Kedah Darulaman Feasibility study of hill site bungalow
Cadangan Membina dan Menyiapkan Jalan Dari Simpang 3 Jenderam ke Pekan Dengkil (B18), Daerah Sepang Selangor Darul Ehsan Geotechnical Investigation of embankment failure and movement at soft ground
Proposed Mixed Development comprises of Parcel 1 (Axis Atrium), 2 (Axis Residence) and 3 (Axis Tower) Alternative foundation design for foundation in limestone.
KVDT Tank Conversion Project at PS Pipeline, Dengkil, Puchong Tank foundation design at Cut & Fill ground
Cadangan Merekabentuk, Membina dan Menyiapkan Kompleks Pasar Besar Baru Secara ‘Design & Build’ Di Mukim Peringgit, Daerah Melaka Tengah, Melaka Geotechnical Investigation of foundation settlement at soft ground.
Geotechnical Investigation Remedial Works for Distressed Wall at Bukit Segar, Cheras, KL Geotechnical Investigation of stability & reinforced soil wall and remedial design
Investigation into the stability of slope at Jalan Tebu, Ukay Heights Geotechnical consultancy services for hill site development
Cadangan Perumahan dan Perniagaan melalui serahbalik dan kurnia semula (peringkat ke2) di atas Lot 4704, Mukim Simpang Kanan, Daerah Batu Pahat, Johor (Sri Gading) Geotechnical Consultancy for soft ground engineering
Foundation Design for High Cost Condominium on part of Lot No. 82, Jalan Persiaran Golf, Saujana Resort, Seksyen U2, 40150 Shah Alam, Selangor Darul Ehsan Full scope geotechnical consultancy for Jack-in foundation system
Proposed Mixed Development on Approximately 366 Acres at Kajang Height, Selangor Darul Ehsan Geotechnical consultancy for fill site development
Cadangan Pembangunan 1 Blok Servis Apartment/Pejabat 33 Tingkat dengan 2 Tingkat Basement di atas Lot 682, 683, 604 – 607 & 611 – 614 Jalan Imbi, Kuala Lumpur Dilapidation study and Geotechnical Consultancy for foundation and basement construction in limestone
Proposed Mixed Development on Lot 7525 & 7526 (212 Acres) at Cheng Estate, Mukim Kelemak, Daerah Alor Gajah, Melaka Full scope Geotechnical for hill-site development
Setting up of Routine Slope Monitoring System  Along Section 2 of SILK Highway Geotechnical assessment and early warning system for cut slope
Show Gallery, USJ Heights Geotechnical consultancy for Foundation
Proposed 21 units Bungalow Development at Jalan Setiabistari, Damansara Heights, KL Independent checking engineer for hill site development
Geotechnical Investigation And Remedial Works For Distressed Cribwall On Lot Pt 5425 (Parcel E) Of Bukit Segar, Cheras, Kuala Lumpur Geotechnical investigation & remedial design for a collapsed crib wall
Investigation into the collapse of the silt trap and remedial works Geotechnical Investigation
Proposed Residential Development Consisting Of Two Blocks Of Highrise Residential Towers With Three-Levels Of Basement At Jalan Tun Razak, Kuala Lumpur Geotechnical Advice
Site Inspection of 59 Units of 1 1/2 Storey Shoplots at Melati Square, Nilai, Negeri Sembilan Geotechnical Inspection
Slope stability at new campus of Universiti Teknologi MARA Geotechnical Investigation into stability of slopes
Country Heights, Damansara, Selangor Darul Ehsan Remedial works for slopes

2005

Project Name Scope
Independent Review Into the Collapse of the Rubblewall and Main Drain at Rawang Investigation on causes of Collapsed Drain
FEM Analysis of Smart Tunnel Shaft Concrete Cover Numerical Analysis of Tunnel
Geotechnical Review for Slope Stability of A9 Road & RE Wall, Damansara Perdana Slope Strengthening on cut slope and RS wall foundation
Geotechnical Review for Rectification Works on Eroded and Rectification Works at Damansara Perdana Slope remedial works on localised erosion
Geotechnical Review on Stability of Rock Slope at Damansara Perdana Geotechnical assessment and strengthening of rock slope
Proposed Steel Plant (DRI/HBI) at Banting Piling foundation and soft ground treatment for industrial structure
Cadangan Membina Dan Menyiapkan Pangsapuri Servis 32 Tingkat (100 unit) Di Atas Lot 206, Jalan Binjai, Seksyen 63, Bandaraya Kuala Lumpur Untuk tetuan Amity Binjai Sdn. Bhd Foundation and Tender design for high rise at Kenny Hill formation.
Site Inspection of PGB Stations in Gurun, Setiawan and Port Klang. Inspection on distressed metering station
Remedial Works of PGB’s NPS 18 Lateral Pipeline at KP 11.5 Monsoon Drain Crossing, Tg. Langsat, Pasir Gudang, Johor Remedial Design on Eroded Drain
Site Inspection for Telecommunication Monopole in Cyberjaya Site Inspection Report
Karachi Port Tower Project in Pakistan Full Geotechnical Consultancy
Expert Opinion on settlement and cracks on building extension at Shah Alam (Kota Kemuning Township) Expert Opinion
Expert Opinion on settlement and cracks on building extension at Shah Alam (Kota Kemuning Township) Expert Opinion
Cadangan Pembangunan Perumahan yang Mengandungi 144 unit Rumah Teres Kos Sederhana Rendah 1 1/2 Tingkat (18′ X 60′) Fasa 1A dan 1 Unit TNB diatas Zone 41, Bandar Indahpura, Mukim Senai, Kulai, Johor Alternative design on foundation system
Cadangan Pecahan Sempadan untuk Pembangunan Kediaman dan Perdagangan di atas Lot 826, Jalan Damansara, Mukim Batu, Kuala Lumpur Routine Maintenance and Engineer Inspections
Soil Investigation Works for Proposed Chung Hwa School in Kota Kemuning, Shah Alam Soil Investigation Works
Engineering Consultancy Service for North-West Corner (66.88 Acres), Damansara Perdana, Kuala Lumpur Full scope consultancy for hill-site development
Proposed 20 storeys high end condominiums on Lot 98, 6 Jalan Stonor, Kuala Lumpur Review of foundation and basement excavation
Cadangan Pembangunan yang mengandungi A) 30 Unit Rumah Berkembar 3 tingkat dan 1 unit rumah pejabat pengurusan 3 tingkat berserta pencawang TNB dan Ruang Mekanikal dan Elektrik di atas Lot 2360, Mukim Batu, Kuala Lumpur Review of hill-site development for semi-detached houses.
Geotechnical Assessment on Slope Stability of entire HR1 Road (500M), Damansara Perdana Slope stability assessment
Proposed Bungalow at 12 Lorong 16/6B, Petaling Jaya Foundation design
Proposed MAS A-380 Hangar/Workshop Facilities and Associated M&E Works at MAS Complex, Kuala Lumpur International Airport Foundation review and value engineering
Investigation of Cracks on Rubble Wall for Desa Parkcity Development Investigation into the cracks on rubble walls
Proposed Sg Takan Bridge at KM 1 + 000 Jalan Takan / Tekalit, Song, Kapit Division, Sarawak Investigation into the stability of the bridge pier
Pulau Indah Transshipment Mega Hub Investigate into driven spun piles breakage
Proposed Bridge Over Pulau Indah Point Interchange Full scope interchange design
Proposed Condominium Development Consist of 2 Condominium Towers and 2 Blocks of 5-Storey Car Park (including Basement) with Recreational Facilities and Commercial Elements (MK10) for Sunrise Quality Sdn Bhd Full scope geotechnical consultants for foundation for highrise on slopes
Proposed Coastal Reclamation Works for About 3300 Acres At Pulau Carey Full Scope Geotechnical Consultancy
Proposed Show Village at MK22 P.T. No. 1891, Jalan Segambut, Kuala Lumpur for Sunrise Berhad Full Scope Geotechnical Consultancy
2.34 Acres, Damansara Perdana Full Scope Geotechnical Consultancy
Proposed Development At Seputeh Heights (Vasana 25) Full Scope Geotechnical Consultancy
Proposed Hume Bebo Arch for Air Craft Shelter At Pasir Puteh, Kelantan Alternative Design of Foundation for Arch Only
Proposed Development for Zone 33A And Kulai Garden, Indahpura, Mukim Senai-Kulai, Daerah Johor Bahru, Negeri Johor Darul Takzim for Messrs Asiatic Land Development Sdn Bhd Full Scope Geotechnical Consultancy
Independent Geotechnical Reviewer to the Design of Remedial Works to Hill 8 of Section C1. Geotechnical Review of Hill-Site Development.
Proposed 80ft. road next to Solaris Dutamas, Sri Hartamas, Kuala Lumpur. Geotechnical Consultant for Road works on slopes.
Proposed bungalow at plot 21 & plot 22 at Country Heights Golden Horse Resort. Geotechnical Consultant for Bungalow
 Cadangan pembangunan satu blok servis apartment/pejabat 33 tingkat dengan 2 tingkat basement di atas lot 682, 683, 604 – 607 dan 611 – 614 Jalan Imbi, Kuala Lumpur.  Geotechnical due diligence for project.
 Cadangan pembangunan perumahan di atas lot 2259, mukim semenyih, daerah hulu langat, selangor.  Geotechnical Review of Hill-Site Development.
 Current compaction practices on buildings and road works for JKR projects.  R&D for earthwork compaction.
 The Residence at Mont’ Kiara, mukim batu, kuala Lumpur for Sunrise Bhd.  Geotechnical Consultancy service for bungalow development.
 Independent consultant to investigate distress on bridge abutment A across Sg. Kundang at km156 and bridge abutment B across Sg. Jempul at km158.5 east coast expressway (ECE).  Geotechnical investigation on causes of distress of abutments.
Cadangan pembangunan fasa 3 yang mengandungi 41 unit rumah Bandar 5 tingkat, 193 unit rumah kondominium dan 1 unit rumah kelab, di atas lot PT6594, jalan 19/70A di taman sri hartamas, mukim kuala Lumpur untuk tetuan sunway D’Mont’ Kiara Sdn. Bhd. Alternative Geotechnical design for reinforced soil wall structure.
Alternative design for rubble wall at section 1 for the proposed development on lots 48572 – 48587, 48590, part of lots 48588 & 48589, mukim batu, kuala Lumpur. Geotechnical design for rubble wall design.
Cadangan pembangunan bercampur di atas tanah bekas hutan simpan ulu gombak (seluas 204 ekar), mukim batu, daerah gombak, selangor darul ehsan. Geotechnical consultants for Hill-Site development.
Cadangan pembangunan bercampur di atas tanah bekas hutan simpan ulu gombak (seluas 204 ekar), mukim batu, daerah gombak, selangor darul ehsan. Geotechnical consultants for Hill-Site development.
Proposed Batang Lebaan Bridge – Geotechnical consultancy service for alternative foundation design (Pakej I & II). Geotechnical alternative design of foundation.
Cadangan pindaan kepada pelan tatatur yang telah diluluskan bagi pembangunan perumahan lot 449, mukim hulu kelang, daerah gombak. Geotechnical report for hill-site development.
Proposed mixed development for the new “Kastam Diraja Malaysia” headquarters, Penang. Geotechnical consultants for buildings on soft ground.
Proposed development of 169 units of high cost condominium at lot no 82, Jalan Persiaran Golf, Saujana Resort, Seksyen U2, 40150 Shah Alam, Selangor. Alternative design of bored pile foundation.
Proposed Bayu Development at Bukit Rimau, Selangor Darul Ehsan. Full Geotechnical consultancy.
Cadangan pembangunan bercampur di atas sebahagian lot 18337 (PT8594) (Plot C), Mukim Tanjong 12, daerah kuala langat, selangor untuk tetuan PNSB dan tetuan Jatidiri Gigih Sdn. Bhd. Geotechnical investigation.
Preliminary Geotechnical Assessment on investigation into cracks on 6 blocks of apartments. Geotechnical investigation.
Soil Slope Investigation. Geotechnical investigation.
Review of pile foundation at proposed two blocks of 19 storey apartments on Lot 64592, Mukim Petaling, Selangor. Review of piling problems in limestone.
Bungalow Walls at Bukit Istana, Klang Geotechnical Review of Retaining Wall.
Cadangan Pecahan Sempadan dan Kenyataan Lot Tanah Pt1329 – PT1340, Lot45232, Lot45233 & Lot 45234 Jalan Batai Barat, Bukit Damansara, Mukim Kuala Lumpur, Wilayah Persekutuan Untuk Tetuan Changkat Kiara Sdn Bhd
Silver Bird Complex, Ground Subsidence Site Inspection.
Proposed bungalow development on Lots 564 & 565 Mukim Hulu Klang, Daerah Gombak, Selangor Full Geotech Consultancy for Hillsite development.
Starhill Centre – Insurance Geotechnical investigation of structural distresses due to ground movement.
Proposed Development of One Bock of 34-Storey Condominium on Lot 114, 115, 116 & 117, Jalan Law Yew Swee, Kuala Lumpur. Review of Foundation.
Expert Opinion on issues related to the compaction of sand. Geotechnical advice on computation of Sand-fill density.
Cadangan kajian, merekabentuk, membina dan menyiapkan sistem saliran di Kampung Chetty dan kawasan sekitarnya, Bandaraya Melaka Bersejarah. Tender Design
Lot 5 & 52 of Taman TAR Full Geotechnical for bungalow lots
Consultancy for EPCC of C&S and Mechanical & Piping Works fro Redline I & II (Package IIC) at PASB, Kerteh Foundation Design of on Shore Structures
Investigation support for Pangkor Landslide Geotechnical Investigation & Remedial works on slope failures
Subsea Facilities at Port Klang Foundation design for plant
Mix Development at Lot 1458, Mukim Cheras, Daerah Hulu Langat, Selangor Darul Ehsan for Messrs. Tetuan Dawang Sdn Bhd Full Geotechnical Consultancy on Hillsite Development

2004

Project Name Scope
Proposed Mixed Development in George Town, Pulau Pinang (ESCOY) Geotechnical Consultancy for Mixed Development with Basement on Ex-Mining Land in Penang
Geotechnical Infrastructure for Bandar Mesra Ilmu Tronoh – Siputeh, Mukim Blanja and Mukim Sungai Terap, Daerah Kinta, Perak Daruk Ridzuan Geotechnical Consultancy for Housing Dev on Ex-Mining Land
Bridge Across Plus Highway at Bernam Jaya – Proposed Alternative Ground Treatment Design. Alternative Ground Treatment Design for Bridge Approach.
Geotechnical Review for Semi-D, Bungalow, Link Houses and Apartments – Taman Sri Bukit Indah, Bukit Mertajam Geotechnical Review for Slopes
Geotechnical Consultancy Service at Damansara Perdana, North West Corner Geotechnical Consultancy for Hillsite Development
Proposed 3.56 acres Mixed Development at Damansara Perdana – Geotechnical Investigation & Strengthening Design for Basement Wall Construction Geotechnical Investigation and Remedial Design for a Steep Cut Slope
Investigation of Slope Failure for Bungalow at Taman Yarl Geotechnical Investigation of Slope Failure
Geotechnical Consultancy Service for Foundation Design for PDB Langkawi Tank Foundation Geotechnical Tender Design for Tank Foundation
Proposed Industrial Park Dev for Factories at Lot 2423 at Tanjung Pelepas, Mukim Tanjung Kupang. Geotechnical Consultancy for Factories on Reclaimed Soft Ground
Proposed 22 units Luxury Apartments on Lot 40397 & 40398, Jalan Medang Serai, Bkt Bandaraya, KL Geotechnical Review of Temporary Works
Strengthening Of Rock Slopes At Ramp H (Ch575-Ch635) Independent Checker for Rock Slopes Strengthening Works
Cadangan Jalan Masuk dan Keluar Melalui Lebuhraya Kesas ke “Centre of Excellence” di atas Lot-Lot 46908 & 46909 (Pt No. 299 & 300) Mukim Damansara Geotechnical Design of Road Extension on Soft Ground
Proposed Forest Resort Development on Approx.  142 acres, Mukim Rawang,  Daerah Gombak, Selangor Geotechnical Consultancy and Road Network / Platform Design for Hill-Site Development
KLHC Suit No. S1-22-172-2000 between Sg. Wang Plaza S/B and Low Yat & Sons Realty S/B & 3 others Expert Opinion on Deep Excavation
Proposed development of 4 blocks of apartment on Lot P.T. 107, Parcel Q, Jalan Perhentian, Sentul, KL Geotechnical Consultancy for Foundation in Limestone
Proposed Development on Lot 1869 (MK23) Geotechnical Consultancy for Highrise Development
Expert Opinion for the case between Negara Properties Sdn Bhd and Cygal Sdn Bhd & Six Others Expert Witness on the collapse of the semi-detached house at Taman Melawati
Cadangan Membina dan Menyiapkan Apartment Kos Sederhana Rendah di atas Sebahagian Lot 1929, Fasa 3, Bandar Baru Puncak Alam, Mukim Ijuk, Daerah Kuala Selangor Expert Witness on the cracks to 5-storey Apartment in Selangor
Cadangan Pembangunan 3 Blok Apartmen dan Podium Letak Kereta bagi Fasa 1B diatas Lot P.T. 36234, Sungai Buloh Alternative Foundation Design
Cadangan Pembangunan Bercampur di atas PT46875 & 46876 Seluas 314 ekar, Mukim Kapar, Daerah Klang Geotechnical Consultancy for 314 acres of housing development on very soft ground
Proposed Mixed Development on 16.05 Acres on Part of Lot PT 31431, Mukim Sungai Buloh, Daerah Petaling, Selangor Darul  Ehsan Alternative Scope Strengthening Design
Proposed Commercial Development Consist of 20 Blocks 5-18 Storeys Shop Office/Office Suite, 2 Open Commercial Elements and 1-4 Storey Car Park (Solaris 2) for Sunrise Alliance Sdn Bhd Geotechnical Development on Mixed Development of 17 acres
Proposed New Sanctuary for Klang Chinese Methodist Church Geotechnical Consultancy for foundation & retaining wall design
Independent Geotechnical Review of Excavation of One MRT Station (OAR) at Alignment C823 Independent analysis of deep excavation
Professional Geotechnical Engineering Consultancy Appointment for the Proposed Construction of a Warehouse and Corporate Office At Lot PT 57332, Taman Berjaya, Seksyen 32, 40460 Shah Alam, Selangor Darul Ehsan Geotechnical consultancy for foundation design on soft ground
Proposed Development on Lot 49370 (PT 15139) and Lot 49371 (PT 15140), Mukim of Petaling, Daerah Petaling, Selangor Darul Ehsan Geotechnical Review of platform stability on ex-mining pond
Strengthening of Rock Slopes At CH17100 – CH. 17175 Only (Exclude Soil Slopes) Design of rock strengthening measure
Cadangan Pembangunan Bukit Perdana Di Atas PT 13430, 13432 Dan 13429, Mukim Ulu Kelang, Daerah Gombak, Selangor Untuk Tetuan Cermat Jaya Sdn Bhd Independent Checker for hill-site development
Expansion of Royal Brunei Naval Base, Muara Package ‘C’ – Piling, Deck & Shiplift Main Contract Independent opinion on pile foundation
Slope Instability At Meru Valley, Ipoh Geotechnical investigation on remedial design for slope instability
The Proposed Hilltop Bungalows Development At Damansara Perdana Geotechnical consultancy for hill-site development
Proposal for Provision of Engineering Consultancy Services for Proposed Bungalow on Plot 275, Mukim of Damansara, District of Kuala Lumpur, Wilayah Persekutuan Geotechnical consultancy for bungalow on hill-site
Cadangan Pembangunan Rumah Link 2 Tingkat di Kg. Tasek Permai, Seksyen 15, Bandar Ampang, Geotechnical Consultancy for Hill Site
Proposed Sports Complex, Negeri Terengganu At Gong Badak, Terengganu Geotechnical Review on the proposed foundation remedial work
Construction and Completion of Submarine Water Pipelines, Watermains at Road R2 (Interchange No. 3 and Southern Chainage) and Other Contingency Waterworks for Pusat Pentadbiran Persekutuan Putrajaya, Selangor Darul Ehsan Investigation of crack of pipes
Great Eastern Phase 2 & 3 Geotechnical Design of foundation
Independent Review into the Collapse of the Rubble Wall and Main Drain at Phase 14B, Bukit Sentosa 2 Geotechnical Investigation of a collapsed monsoon drain

2002 – 2003

Project Name Scope
Kajang Traffic Dispersal Ring Road – Interchange H: Mining Pond and Surround (CH2080 – CH2340 and Sg. Ramal Bridge Approaches (CH610-CH780 and CH840 – CH920) Alternative value engineering ground treatment design.
Proposed Phase 1 (low cost) Development of Lot PT 10177 – PT10182, Mukim Ampang, Hulu Langat, Selangor Alternative foundation design.
Batu Gajah Railway Development – KTM (Phase 1) for EMU Depot & Yard Geotechnical planning & conceptual design.
Design for the Remedial Work to alleviate softground problems at KM58 Alor Setar (S) to Sg. Petani (S) Expressway, Section N2 Remedial design for soft ground mushroom effects using 3D-FEM analysis.
Pengkalan Kastam Merin, Sg. Pulai, Tanjung Kupang, Johor Geotechnical design of sheet pile retaining structure in river front of marine deposite.
Proposed development of house shops & 5-storey office lots with basement on Lot PT41, Seksyen 54, Bandar Kuala Lumpur Wilayah Persekutuan for Sritamas Sdn Bhd Geotechnical consultancy for basement excavator and foundation in lime stone foundation.
Proposal for Turnkey Project, PT. Multigambut Industri, Riau, Sumatera , Indonesia Geotechnical consultancy of geotechnical design for palm oil mill over alluvial deposite.
Geotechnical Consultancy for Site Inspection of Wisma CycleCarri, Wisma Weld and Bintang Pantai Condo, Kuala Lumpur Inspection of Building over hillside for Insurance company’s requirement.
North-South Expressway- The Design for The Remedial Works to Alleviate Softground Problems (Mushrooming) at KM46.7 and KM71 of the North South Expressway, Section N2 Engineering research on the use of shallow RC raft remedial to Mushroom effects of soft ground.
Proposed Bridge over Sg. Kerang for Ladang Gemilang, Gedong, Sarawak Foundation design for bridge and approach embankment over soft ground and river.
Ground Treatment to Double Tracking Project Ground treatment design for double track rail projects for Ipoh to Padan Besar (328KM)
Proposed Development on Lots 2373 & 2374 (Parcel B), Bukit Kiara, Kuala Lumpur Geotechnical designs for retaining structure slope stabilisation works and foundation design.
Proposed Kabong Police Station, Sri Aman Division, Sarawak Geotechnical consultancy service for softground engineering and foundation.
Proposed housing development on Lot 2832, 2833, 2834, Mukim Cheras, Daerah, Hulu Langacct, Mukim Dengkil, Daerah Sepang, Selangor Geotechnical consultancy in pound reclamation and foundation design for residential development
Proposed 16 tanks at Petrochemical Jetty, Westport , Port Klang Geotechnical consultancy for tank foundation in reclaimed land over soft marine deposite.
Proposed Low and Medium Cost Apartment at Jinjang Utara, Kuala Lumpur Geotechnical consultancy for foundation design & ground treatment at ex-landfill
The Proposed 3 units of 4-storey shop office on Lot 947, 948, 949, 950, 1138, 1139, 1140, 1141, Sek. 62, Changkat Thamby Dua, KL Geotechnical consultancy for Jack-in foundation design in lime stone area.
Proposed Development of 2-Storey Medium Cost Terrace Houses (Phase 1C), Water Tank & Related Works on Lot PT 15139 dan PT15140, Taman Tasik Prima, Mukim Petaling, Daerah Petaling, Selangor for Prima Nava Harta Development Sdn Bhd Geotechnical consultancy for Jack-in foundation design in lime stone area.
Proposed development of a double storey bungalow on Lot 39967 , 39968 , 39969 and 39970, Mukim Batu, Kuala Lumpur Preliminary geotechnical design of foundation design.
Proposed 6 units of Bungalow Comprises of Lots B176, B180, C218, C228, C231 & C235 at Bukit Tinggi Resort, Mukim of Bentong, Pahang Geotechnical investigation and slope stabilisation works for bungalow development at hill-site.
Proposed redevelopment on Lot 164 & 759, Seksyen 6 & 9, Bandar Kota Bharu, Kelantan Darul Naim for Finconsult Sdn Bhd and Perbandaran Kemajuan Iktisad Negeri Kelantan Geotechnical consultancy service for frictional piled foundation design at alluvial desposite in river bank.
Geotechnical investigation into collapsed of 11 berm slope at CH15+425 to CH15+700, Package 4B, Simpang Pulai-Lojing-Gua Musang Highway, Kelantan Geotechnical investigation on collapse of high road cut slope.
Proposed 10 units of Bungalow on Lots B29, B31, B35, B36-B39, B42, B44, C8 at Bukit Tinggi Resort Geotechnical investigation and slope stabilisation works for bungalow development at hill-site.
Kuala Lumpur – Putrajaya Dedicated Highway Geotechnical ICE for the Expressway.
Geotechnical investigation and remedial works for gas pipeline at Salak Tinggi, Selangor Geotechnical investigation & remedial design of a debris flow callapse.
Proposed Luxury Condominium development of 112 units at Lot 96, Persiaran KLCC, Kuala Lumpur Geotechnical consultancy service for 3 level basement & foundation design in Kenny Hill formation.
Proposed bungalow development on Lots 501, 502 & 503 Mukim Hulu Klang, Daerah Gombak, Selangor Geotechnical consultancy service for hill-site development.
Proposed Development on Lot 55335 (106130), Mont Kiara (K6), Kuala Lumpur (Solaris) Geotechnical consultant for the project.
Proposed Foundation System Design for the view project on Lots 3319, 3320, 3321, 3322, 3330, 4681, 4683, and 4684, MK 13, D.T.L., Jalan Sultan Azlan Shah, Penang for Ivory Villas Sdn Bhd (The View) Alternative value engineering foundation design for the twin towers of Penang.
197KM West Coast Expressway from Taiping to Banting. Geotechnical consultant for the expressway.
Geotechnical Investigation into failure of sheet pile wall at Sentosa II, Bukit Beruntung, Selangor Geotechnical investigation of collapse of main monsoon drain.
Slope Failure in Kupang, Kedah ( East-West Highway , Kupang to Gerik) Geotechnical investigation on collapse of highway cut slope.
Geotechnical Investigation and Assessment on Embankment Stability and seepage, buoyancy for an Excavation Geotechnical investigation of an embankment stability with a basement construction next to a pond.
Kiara Designer Suites Located at Mont’ Kiara, Kuala Lumpur, Kiara Designer Suites is one of the Sunrise Paradigm Sdn Bhd projects consisting of one block of 29-storey service apartment, one block of 6-storey car park with recreation facilities and commercial space, and 2-storey of service apartment on top of the car park. Cost of project is approximately 90 million.

1999 – 2001

Project Name Scope
Berjaya Star City Full Scope Geotechnical Consultancy.
Sungai Selangor Dam Independent Checking Consultancy Rockfill Clay Core Dam Design.
3 Blocks of 16-18 storey Building (948 units), Ampang, KL Full Geotechnical Consultancy Service on Foundation in Limestone.
PSI-Instun/ PSI-ITM Perak/ PSI-ITM Johor/ PSI-ITM Melaka/ PSI-ITM Sarawak/ PSI-Labuan Matriculation/ PSI-ITM Sabah Full Geotechnical Consultancy Service on Geotechnical Work.
Tawau Airport Sabah Independent Review on Expensive Subgrade Compacted Material on Runway.
Independent Review Into the Collapse of the Rubblewall and Monsoon Drain at Block A of 5-storey Apartment, Phase 1DA of Sentosa II, Bukit Beruntung, Selangor Forensic Investigation on Collapsed Rubble Wall on Top of RC Monsoon Drain.
Design, Construction & Commissioning of Kolej Matrikulasi & Associated Facilities on Lot 137664, Gopeng, Perak Full Geotechnical Consultancy Service on Geotechnical Work
Design, Construction & Commissioning of Kolej Matrikulasi & Associated Facilities on Lot PTD 16944, Tangkak, Johor Full Geotechnical Consultancy Service on Geotechnical Work
Proposed UiTM Branch Campus, Arau Perlis Full Geotechnical Consultancy Service on Geotechnical Work
Cyberjaya Phase 2 Mixed Development Overall Planning of Earthworks.
Consultancy services for the study of settlement problem along the first 1.2km of Jalan Kundasang Golf Course, Sabah Forensic Investigation of Massive Creep Moment of Post Glacial Desposive.
Kuantan Kerteh Railway Project Geotechnical Alternative Design for Railway Embankment.
Proposed 400 units – 2 blocks of 5 storey Low Cost Apartments at Lot 36234, Mukim Sungai Buloh, Daerah Petaling, Selangor Darul Ehsan Full Geotechnical Consultancy on Foundation Design at Granitic Formation.
Batu Gajah Railway Development – KTM Geotechnical Planing & Conceptual Design.
Kolej Matrikulasi Pahang Full Geotechnical Consultancy Service on Geotechnical Work.
Kolej Matrikulasi Kedah Full Geotechnical Consultancy Service on Geotechnical Work.
Jica Slope Study for East-West Highway Slopes. Geotechnical Study of Slopes & Instrumentation Monitoring.
Geotechnical Consultancy for 22.55 Acres Affordable Homes at Damansara Perdana, Selangor (Flora Damansara) Geotechnical Consultancy for Highrise Residential Block at Hill-Site
Construction of Six Blocks of 16-18 Storeys 1896 Flat Units and Related Works for “Program Perumahan Rakyat” at Bukit Jalil 1, Mukim Wilayah Persekutuan, Kuala Lumpur. Geotechnical Consultancy for Highrise Residential Blocks at Sedimentary Formation.
Damansara Perdana, 5.14 acres Mixed Development Geotechnical Consultancy for Geotechnical Work for Highrise Residential Development.
Geotechnical Investigation on Wall Stability with Cut Slopes by Adjacent Development and Water Tank on Blasted Rocks and Consultancy Services for the Strengthening Works Geotechnical Investigation & Remedial Work for Blast Damage Rocks foundation for Water Storage Tank.
Geotechnical Expert Opinion for Slope Failure at UTM Skudai, Johor Bahru Forensic Investigation & Remedial Work for a Collapsed Slope.
Sekolah Kebangsaan Taman Bersatu, Mukim Teluk Kechai, Kedah Geotechnical Consultancy for Soft Ground Engineering.
Geotechnical investigation into failure to bungalow and wall collapsed behind bungalow at Zone 7, Bukit Beruntung, Selangor Forensic Investigation of a Distressed Bungalow Near to a Collapsed Wall.
Geotechnical Investigation into Landslips Failure Adjacent to Taman TAR Development Forensic Investigation & Remedial Works of a distressed Slope Behind a Residential Apartment.
Proposed Development of Two Blocks of 30-Storey Condominium with 345 Units and 1 Block of Carpark and Recreational Park on Part of Lots 21745, 21746 & 21747 Mukim Batu, Kuala Lumpur for Sunrise Berhad (MK8) (Mont’ Kiara Aman) Full Geotechnical Consultancy Scope.
Proposed construction and completion of Light Rail Transit Infrastructure works and central boulevard package at Precint 3 of the Putrajaya Core Island Dev. Package LRT-Blvd – Alternative Design Alternative Support System for 17M CBP Pile Wall for Cut & Cover Tunnel Construction.
